LCD Modules LCM Alphanumeric GREEN

LCD Modules Pricelist   How to Order

Character LCM (LC Modules), green display
  • Viewing direciton: 6 o'clock (bottom view)
  • Fluid type: STN
  • Polarizer type: Transreflective
  • Yellow LED backlight
  • Duty cycle: 1/16
ATM0802A-FL-YBW
  • Item: ATM0802A-FL-YBW
  • Module format: 8x2
  • Backlight voltage: 5/3.3V
  • Module Size:
    40x35.4 mm (WxH)
  • View Area: 30.4x13.9 mm (WxH)
  • Character Size:
    2.95x4.75 mm (WxH)
  • Dot Size: 0.55x0.55 (WxH)
  • RoHs compliant, Weight: 20g
ATM1602B-FL-YBW
  • Item: ATM1602B-FL-YBW
  • Module format: 16x2
  • Backlight voltage: 5/3.3V
  • Module Size:
    84.0x44.0 mm (WxH)
  • View Area: 64.5x16.4 mm (WxH)
  • Character Size:
    3.00x5.23 mm (WxH)
  • Dot Size: 0.56x0.61 (WxH)
  • RoHs compliant, Weight: 45g
ATM1602S-FL-YBW
  • Item: ATM1602S-FL-YBW
  • Module format: 16x2
  • Backlight voltage: 5/3.3V
  • Module Size:
    122.0x44.0 mm (WxH)
  • View Area: 99.0x24.0 mm (WxH)
  • Character Size:
    5.20x9.55 mm (WxH)
  • Dot Size: 1.00x1.15 (WxH)
  • RoHs compliant, Weight: 60g
ATM1604C-FL-YBW
  • Item: ATM1604C-FL-YBW
  • Module format: 16x4
  • Backlight voltage: 5/3.3V
  • Module Size:
    87.0x60.0 mm (WxH)
  • View Area: 61.8x25.2 mm (WxH)
  • Character Size:
    2.95x4.75 mm (WxH)
  • Dot Size: 0.55x0.55 (WxH)
  • RoHs compliant, Weight: 55g
ATM2002D-FL-YBW
  • Item: ATM2002D-FL-YBW
  • Module format: 20x2
  • Backlight voltage: 5/3.3V
  • Module Size:
    116.0x37.0 mm (WxH)
  • View Area: 83.0x18.6 mm (WxH)
  • Character Size:
    3.20x5.55 mm (WxH)
  • Dot Size: 0.60x0.65 (WxH)
  • RoHs compliant, Weight: 60g
ATM2004D-FL-YBW
  • Item: ATM2004D-FL-YBW
  • Module format: 20x4
  • Backlight voltage: 5/3.3V
  • Module Size:
    98.0x60.0 mm (WxH)
  • View Area: 76.0x25.2 mm (WxH)
  • Character Size:
    2.95x4.75 mm (WxH)
  • Dot Size: 0.55x0.55 (WxH)
  • RoHs compliant, Weight: 75g
Those are our basic items, we can also tailor make another types, minimum order 1000 pcs (depends on type):
  • View: 3, 9, 6 or 12 o'clock (right, left, bottom or top view)
  • TN or STN
  • With or without backlight
  • Reflective, Transreflective, Transmisive (positiv or negativ)
  • Any backlight color (LED or panel)
  • Order number: ATMab-cd-efg
    • a = module format (1601 = 16x1 char.)
    • b = design version (A through Z for different PCB sizes)
    • c = polarizer type (R=reflextive, F=transreflective, M=transmissive positiv, N=transm. neg.)
    • d = Backlight type (N=none, E=EL, S=side lit LED, L=LED, C=CCFL)
    • e = Fluid type (B=blue mode STN, Y=Yellow mode STN, RB=blue mode STN with RED backlight, F=FSTN, T=TN, G=gray mode STN)
    • f = Viewing direction (R=right view = 3 o'clock, L = leftview, 9 o'clock, B=bottom view = 6 o'clock, T = topview, 12 o'clock)
    • g = temperature (W = wide 0-70 °C, S = standard 0-50 °C)
